Daikin's FTKF50XV gives an unmatched air conditioning experience. Its 3D Airflow feature circulates a cloud of cool air right to the corners of even large spaces. With its even cooling and advanced features like ECONO mode.
| Model name | Indoor unit (IDU) | FTKF50XV16MAA |
| Outdoor unit unit (ODU) | RKF50XV16MAA | |
| Star Rating* | 5 Star | |
| Rated Power supply (Phase/Frequency/Voltage ) | (220-240V)1Φ 50Hz 230V | ✔ |
| Rated Cooling Capacity | kW | 5 |
| Cooling Capacity (Min. ~ Max) | kW | 2.0~6.0 |
| 100% Cooling Capacity Temperature | ℃ | 46°C |
| Rated ISEER | Wh/Wh | 6.3 |
| Rated Annual Power Consumption | kWh | 614.76 |
| Air Flow Rate (Cooling /Heating) | CFM / CMM | 671 / 19 |
| Voltage Range | V | 130~285 |
| Ambient Temperature Range | Cooling(Min~Max) | 10°C~55°C |
| Minimum IDU Sound Level | (dBA) | 31 |
| Operating Current (Cooling/Heating) | A | 4.91 |
| Key USPs | Patented Swing Compressor | ✔ |
| Patented Streamer Discharge | x | |
| Intelligent Eye (Energy Saver and Auto ON/OFF) | x | |
| Smart phone app control (Wi-Fi) | x | |
| Voice Control (Amazon Alexa and Google Home) | x | |
| 3D Air Flow | ✔ | |
| Triple Display | ✔ | |
| Power Airflow Dual Flaps | ✔ | |
| Power Chill | ✔ | |
| Econo Mode | ✔ | |
| Remote Backlit | ✔ | |
| Dew Clean | ✔ | |
| Hepta Sense | ✔ | |
| Self Diagnosis | ✔ | |
| Stabilizer Inside | ✔ | |
| Filter Clean Indicator | ✔ | |
| Air Purification | Prefilter With Anti Bacterial Coating | ✔ |
| Smell Proof Operation | ✔ | |
| Special filter 1 | PM1.0 | |
| Special filter 2 | 3 Layer Filter | |
| Anti corrosion | DNNS Self Heal | ✔ |
| BTA Oil Treatment | ✔ | |
| Blue Fin Coating for ODU | ✔ | |
| Safety | Multi Layer Fire Safety | ✔ |
| Controls | Display Off funtion | ✔ |
| IDU LED Brightness Control | ✔ | |
| Child Lock | ✔ | |
| Piping length | (Max Length/Max Height) m | 25/20 |
| Piping Connection | Gas/Liquid mm(Inch) | Φ12.7 & Φ6.4 (1/2”&1/4”) |
| Dimensions (HxWxD) mm | IDU | 325 x 1060 x 278 |
| ODU | 695 x 930 x 350 |
Cooling capacity is based on: indoor temp. 27°C DB, 19°C WB; outdoor temp. 35°C DB, piping length 5 m.
Sound levels are based on temperature conditions 1. above with 5m piping length. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.
Cooling and heating capacities above are rounded off to first decimal. 1TR (Ton of Refrigeration) = ~3.517 kilowatt.
*Star Rating mentioned above is as per norms defined by Bureau of Energy Efficiency, Ministry of Power, Government of India.
” Value given in Inch. #As per Continuing Policy of Product Innovation at Daikin, The Design, Technical Specifications, Features, Look may change without prior notice.
